From Atoms to Chips: How Fudan’s ATOM2CHIP Advances 2D Material Integration into Real-World Devices

Two-dimensional (2D) materials—atomically thin semiconductors, insulators, and conductors—have long promised a future of electronics at ultimate scaling and efficiency. But bridging the gap from lab-scale devices to full, usable chips remains a daunting challenge. In a recent breakthrough, Chunsen Liu and collaborators at Fudan University demonstrated a fully functional NOR flash memory chip built with 2D materials grown directly onto a standard CMOS silicon die. Their result, published October 9 in Nature, could be a turning point for 2D electronics.

In this post, we’ll dive deeper than the initial coverage. We examine the innovations behind ATOM2CHIP, place them in the landscape of prior 2D–CMOS integration work, assess the obstacles to scaling, and explore how this advance might reconfigure memory, compute, and chip architecture in the AI era.



What They Achieved: A Snapshot

Liu et al. delivered a hybrid chip that merges a 2D NOR flash memory array on top of a 0.13 µm CMOS control logic platform. Key performance and yield figures include:

Full chip yield: 94.34%, competitive with mainstream silicon process benchmarks.

Operating frequency: up to 5 MHz

Per-bit energy: ≈ 0.644 picojoules

Programming / erase latency: ~ 20 ns

Data retention: ~ 10 years

Endurance: > 100,000 write cycles

These numbers place the chip in a regime where it begins to compete with conventional flash on key metrics, rather than merely serving as a proof-of-concept.

Moreover, the researchers addressed a perennial barrier in 2D integration: nanoscale surface roughness of silicon substrates. They developed a conformal adhesion process to allow the atomically thin MoS₂ layer to “flow over” contours without tearing, combined with 2D-friendly packaging to guard against thermal and electrostatic damage. At the same time, they designed a cross-platform interface enabling the 2D memory module to speak seamlessly to CMOS logic with instruction-driven access and 32-bit parallelism.

Liu’s team frames ATOM2CHIP as a “full-stack on-chip process + cross-platform system design” blueprint to move 2D electronics out of academic isolation and toward real chips.



Placing This Work in the 2D Integration Landscape

To truly appreciate the import of ATOM2CHIP, we need to see how it builds upon—and surpasses—previous efforts.

The promise and perils of 2D electronics

2D materials (such as transition metal dichalcogenides, e.g. MoS₂, WSe₂) have attractive properties at ultra-thin thickness: high mobility (in some cases), strong gate control, immunity to short-channel leakage, and the ability to stack via van der Waals interactions. Researchers have pursued 2D-based transistors, sensors, photonics, and memory for over a decade. But translating single devices into working circuits on silicon has been the bottleneck.

Some of the core obstacles include:

High contact resistance at 2D–metal interfaces

Difficulty depositing or integrating high-quality dielectrics on bond-free 2D surfaces

Selective doping (n- vs p-type) within 2D layers

Thermal budget constraints (many 2D deposition methods require fairly high temperature)

Mechanical stress, cracking, edge defects when applying 2D layers over textured surfaces

Lack of modeling / design infrastructure (PDK, SPICE models) for 2D elements

Review articles on CMOS-compatible 2D synthesis note that while many device-level demonstrations exist, industrial adaptation remains in a nascent stage.

What sets ATOM2CHIP apart

Much of previous 2D–CMOS hybrid work involved one or more concessions: transferring 2D films post-fabrication, building only individual devices or small arrays, or limited interfacing to CMOS logic. What Liu’s team did differently:



In-situ growth / integration on a real CMOS die: They did not merely place a 2D film on a dummy substrate. They built memory directly on top of controller circuitry.

Scalable full-chip yield: They achieved >94% yield at full-chip scale, suggesting uniformity and defect control across the die.

Full-featured memory behavior: The chip supports instruction-level control (8-bit commands), 32-bit parallelism, random access—not just a static array.

Overcoming surface roughness: Their conformal adhesion and mechanical accommodation is a notable engineering innovation, addressing a very practical barrier often overlooked in lab prototypes.

Cross-platform design bridging 2D and CMOS domains: They designed the interface carefully to manage voltage levels, drive capabilities, control logic, and error mitigation.

In other words, this is not just a better memory device—it is an integrated system marrying 2D and CMOS in a real chip.

Still, one must note: this work was demonstrated on a relatively mature 0.13 µm process node. The big question is: can these techniques scale downward (e.g., to 65 nm, 28 nm, or beyond)? And can they be folded into real foundry toolchains? We address those next.



Engineering and Manufacturing Hurdles & Scalability

Even with ATOM2CHIP’s achievement, the road toward commercial relevance is long. Here are the principal challenges and considerations.

Yield, variability, and reproducibility

A 94.34% yield on one or a few chips is impressive—but scaling to wafer-level, multi-batch production is a very different prospect. Yield degradation could arise from particulate contamination, film non-uniformity, defect clustering, or edge effects across wafer boundaries.

Furthermore, the distribution of performance across memory cells (e.g. threshold voltage variation, leakage, endurance spread) must remain tight. Any wide spread would demand error correction overhead or binning, reducing effective yield.

To build confidence in ATOM2CHIP’s viability, one would want:

Multiple wafers, multiple lots yield data

Spatial uniformity maps (e.g. defect density across die)

Variation statistics (mean, sigma) for speed, power, retention

Stress/aging testing across multiple units

Until such published data appear, the leap from “promising prototype” to “foundry-ready module” must remain cautious.

Compatibility with standard foundry flows

Integrating 2D layers into a commercial CMOS process demands minimal disruption to existing tools and modules. Some issues:

Thermal budget constraints: Back-end-of-line (BEOL) or post-CMOS depositions often must stay below ~400 °C to prevent damage to underlying devices or metal interconnects. (e.g. CVD) may require higher temperatures, risking damage or diffusion.

Contamination control: Introduction of chalcogenides (e.g. sulfur, molybdenum) into a standard fab may challenge contamination rules and cross-contamination with other tool modules.

Integration with lithography / patterning: Patterning 2D layers (etch, alignment) must be compatible with existing photolithographic tolerances (EUV, DUV). Some work explores EUV-compatible patterning of TMDs.

Interconnect / via integration: How to make reliable contacts between the 2D layer and metal layers without damaging either—or generating high contact resistance—remains delicate.

Back-end packaging and protection: The paper mentions a “2D-friendly packaging system” to guard against heat or ESD damage. That packaging must be compatible with standard die assembly, encapsulation, and test flows.

Some alternate integration strategies exist (e.g. low-temperature transfer, wafer bonding, van der Waals stacking) but each has trade-offs in defectivity and mechanical strain.

Design infrastructure and PDK gap

Even if the materials and processes can be made reliable, adoption hinges on having a mature design infrastructure:

PDK (Process Design Kit) for 2D devices: Accurate SPICE/compact models, extraction rules, parasitics, mismatch models. These must co-exist with the conventional CMOS PDK.

Tool support (CAD, place & route, verification): Tools must support mixed domains (2D logic, 2D memory, CMOS) with duty-aware timing, bounding of process corners, variation-aware design.

Test patterns / ATE support: Automated test equipment must be adapted to test 2D cell arrays (program/erase cycles, retention, stress) at wafer sort or burn-in phases.

Reliability & qualification standards: The industry expects multi-decade lifetimes, failure modes analyses (e.g. hot carrier, electromigration, thermal cycling). Doing so for 2D materials is nascent.

Without a robust design and test ecosystem, even compelling chips struggle to migrate beyond prototyping.



Process node migration (shrinking and performance scaling)

To integrate into modern logic or memory stacks, the demonstrated techniques must migrate to more advanced nodes (e.g. 65 nm, 28 nm, 7 nm). But that migration brings additional stress:

Smaller feature sizes amplify variation and defects

Stricter alignment, overlay, and lithographic tolerances

Higher demands on contact resistance, parasitic capacitance, and interconnect delays

Greater integration density and heat dissipation constraints

If ATOM2CHIP techniques scale, they may offer a path for so-called “CMOS 2.0” architectures, where heterogeneous layers (2D + Si) coexist. Indeed, technology roadmaps such as those from IMEC anticipate hybrid layering of 2D memory or function layers above CMOS logic.

It remains to be seen whether the mechanical adhesion, interface quality, and defect densities can keep pace as dimensions shrink.



Why It Matters: Implications for Architecture, Memory, and Compute

Even if we assume optimistic scaling, what might a hybrid 2D/CMOS future look like? Here are a few visions:

Reinvigorating Moore’s Law via heterogeneous scaling

Classic Moore’s Law (smaller transistors, more density) is hitting physical limits. But if we can overlay functional 2D layers (memory, sensors, accelerators) on top of logic, we effectively gain "vertical" scaling without shrinking transistor gates. In that sense, 2D–CMOS integration becomes a way to extend scaling in a heterogeneous dimension. Many researchers refer to this as “More-than-Moore” or “CMOS + X” strategies.

For example, a SoC could have:

Logic and control in mainstream CMOS

An embedded 2D memory tier (fast, low-power, dense)

Specialized functional blocks (e.g. photonic modulators, analog synapses, sensors) built in 2D

Vertical interconnects binding all layers

In this model, memory is no longer bolted on but sits intimately atop logic, reducing latency, power, and chip footprint.



A new memory hierarchy and compute-in-memory opportunities

If 2D memory achieves parity with CMOS flash in speed/energy, it could shift the memory hierarchy:

2D memory could serve as a near-cache or extended on-chip storage (faster and closer than off-chip flash)

It could enable compute-in-memory architectures: one might embed simple logic or bitwise operations directly within 2D layers, reducing data movement.

For AI accelerators, embedding large, local memory with ultra-low energy per bit access becomes critically valuable (bandwidth bottleneck alleviated).

Even more, the intrinsic properties of 2D materials (e.g. low leakage, steep subthreshold slopes) might help push novel nonvolatile memory designs (resistive switching, ferroelectric 2D devices) closer to practical deployment.



Power and footprint gains for edge / IoT devices

Ultra-low energy per bit and compact stacking make 2D-enhanced chips attractive for energy-constrained devices (sensors, wearables, implants). These devices may benefit more quickly from hybrid integration because the performance demands are less aggressive, and power/area savings matter more.

Risk and strategic value in geopolitics

Semiconductors are a linchpin technology in global competition. A viable 2D/CMOS integration technique could become a strategic asset:

Countries or firms proficient in hybrid 2D processes might leapfrog certain nodes

IP controls, export restrictions, or strategic alliances around 2D integration may emerge

Early lead in 2D integration might shape supply chains for next-gen memory or accelerator chips

Thus, the research should be seen not only as a scientific advance but as a potential harbinger of strategic shifts.



What the Research Community (and Industry) Should Do Next

To realize the promise, several focused efforts should follow:

Wafer-scale, multi-lot reproducibility trials
Demonstrate consistent yield and performance across full wafers and multiple batches to validate manufacturability.

Scaling studies to advanced nodes
Port the ATOM2CHIP methodology from 0.13 µm to 65 nm, 28 nm, or beyond, characterizing variation, contact resistance, and interface stability.

Extended reliability and stress testing
Run high-temperature, humidity, thermal cycling, and accelerated aging tests to validate retention, endurance, and failure modes.

Collaboration with foundries
Engage CMOS fabs to assess contamination compatibility, tool integration, and process insertion strategies.

Open or shared PDK and modeling efforts
Publish compact models, simulation tools, and extraction rules to enable third-party design verification and prototyping.

Explore alternative 2D materials and heterostructures
For example, WSe₂ (p-type), black phosphorus, or van der Waals heterojunctions might expand functionality (e.g. logic, photonics) beyond MoS₂ memory.

Integration with 3D / 2.5D architectures
Examine combining 2D layers with advanced interposers or TSVs to optimize vertical interconnect and stacking flexibility.

Benchmarking vs state-of-the-art flash / emerging memory
Place results side by side with commercial flash, ReRAM, MRAM, showing where 2D memory wins or lags in real-world tasks.

Open replication and benchmarking
Encourage independent groups to replicate the process and share results, strengthening confidence.



A Balanced View: Strengths, Caveats, and What to Watch

Strengths to applaud:

ATOM2CHIP accomplishes what many have tried but few succeeded in: integrating a 2D memory directly on CMOS logic with real-world performance and yield.

The engineering of conformal adhesion is nontrivial and addresses a real-world problem that often kills 2D film reliability over real-world topography.

The cross-platform interface and instruction-level support push this beyond toy arrays into usable memory modules.



Caveats to keep in mind:

The node choice (0.13 µm) is relatively old; the real pressure is in sub-100 nm domains.

Single-chip yield is promising but not proof of scalable yield.

Some key details (e.g. long-term stability under stress, wafer-level uniformity, defect distributions) remain undisclosed in public summary.

Integration into commercial fabs demands overcoming contamination, thermal, and process compatibility hurdles.



What to watch in the coming years:

Publication of multi-wafer, multi-batch statistical yield data

Demonstrations ported to more advanced nodes (e.g. 65 nm, 28 nm)

Reports of 2D memory embedded into real SoCs or AI accelerators

Development of open PDKs and third-party designer adoption

Industrial partnerships or foundry announcements to adopt hybrid 2D modules

If those happen, we may be witnessing a genuine turning point in semiconductor evolution—not simply a lab novelty.



Concluding Thoughts

Fudan’s ATOM2CHIP represents a bold stride toward integrating 2D materials into real, usable chips. It demonstrates that by combining clever materials engineering (conformal adhesion, packaging) with system-level design (cross-platform interfaces), one can transcend many of the barriers that have plagued 2D–CMOS integration.

Still, the road ahead is far from trivial. Scale, reliability, process compatibility, and ecosystem support remain formidable challenges. But if the community seizes this momentum—publishing open models, engaging foundries, pushing node migration—then a hybrid 2D/CMOS future may not be purely speculative.

In a world where Moore’s Law is fraying, innovations like this hint at a new dimension of scaling. If we can stack memory, logic, and specialty functions vertically—through heterogeneous integration instead of continuous miniaturization—then the next decade of semiconductor advancement may look less like shrinking, and more like layering smarter.

Stay tuned. The era of 2D-in-chips may just be turning the corner.
