Cat5e Foiled + Braided Shielded Twisted Pair Cable

Cat5e Foiled + Braided Shielded Twisted Pair Cable

Prix habituel $208.19
Prix habituel $229.01 Prix promotionnel $208.19
En vente Épuisé
Frais d'expédition calculés à l'étape de paiement.
Specification
Color

Product Name: Cat5e Foiled + Braided Shielded Twisted Pair Cable
Twisting Method: 8-core 4-pair twisted pair, 4 pairs of 2 single conductors twisted together to form 1 pair
Wire Gauge: 24AWG single core high-quality oxygen-free copper, bare copper, stranded copper
Jacket: Environmentally friendly PVC, CM grade flame-retardant polyvinyl chloride, 0.56mm thickness
Transmission Rate: 100Mbps
Bending Radius: 1 inch (4 times the cable diameter)
Conductor Material: High-quality oxygen-free copper
Copper Core Diameter: ₵0.515mm (24AWG)
Wire Core Diameter: ₵0.97mm ± 0.03mm
Finished Wire Diameter: 6.4mm ± 0.02mm
Insulation Material: High-density polyethylene HD-PE
Impedance: 100ohm + 15%, 1 MHz to 100MHz
Operating Temperature: -20°C to 60°C
Performance: Meets 100Base-TX Gigabit Ethernet standards
Tensile Strength: ≤93N
Weight (including packaging): 15kg
Size (box packaging): 452845 (cm)
Specification: 305 meters per box
