- Model
- HB707 11IN1
- Color
- Gray (Sandblasted Anodized Aluminum)
- Port Type
- USB-C, USB-A, HDMI, RJ45, SD, TF, Audio Jack
- USB Version
- USB 3.0 Gen1 (5Gbps)
- Number of Ports
- 11 Ports
- Data Transfer Speed
- Up to 5Gbps (USB-A & USB-C Data Ports)
- USB Ports
- 3 × USB-A 3.0 Gen1, 1 × USB-C 3.0 Gen1 (5Gbps)
- HDMI Ports
- 2 × HDMI Ports
- Max Resolution (Single Display)
- 3840×2160@60Hz
- Max Resolution (Dual Display Mirror)
- 3840×2160@60Hz (requires host & monitor support)
- DP1.2 Compatibility
- 4K@30Hz (single), 1080P@60Hz (mirror)
- DP1.4 Compatibility
- 4K@60Hz (single/mirror)
- USB-C Power Delivery
- 1 × USB-C PD Port (Supports 20V/5A, Max 100W input, 85W actual tested output)
Dynamic power negotiation supported
- Charging Ports
- Yes (PD Port for charging only)
- Fast Charging Support
- Yes (PD3.0 Protocol)
- Audio Port
- 3.5mm Audio Jack (Supports Left/Right Channels, Mic Input, and In-line Controls)
- Ethernet Port
- 1 × RJ45 Gigabit Ethernet (10/100/1000Mbps)
- Card Reader
- SD 3.0 + TF 3.0
Dual Card Simultaneous Access
Dual Drive Letter Support
- Material
- Aluminum Alloy (Sandblasted Anodized Finish)
- Compatibility
- macOS, Windows 10/11, Android
Supports USB-C devices with DisplayPort Alt Mode
Not compatible with Nintendo Switch
Does not support BC1.2 protocol
- Overcurrent Protection
- USB-C Port: 5V/1.4A
USB-A Port: 5V/1.5A
- Standby Current
- 5.219V / 0.309A
- Chipset Combination
- VL103R (PD 3.0 Controller)
RTD2143 (HDMI Video Chip)
2 × GL3510 (USB 3.0 HUB)
RTL8153B (Gigabit Ethernet Controller)
GL3224 (SD/TF 3.0 Card Reader)
SC8724 (Step-down Converter)
HI613M (Audio Codec)
VL171 (Switch Controller)
- Plug and Play
- Yes
- Shell Dimensions
- 250mm × 55mm × 16mm
